Scanning

Output greyscale depth

8 bit

Output monochrome depth

1 bit

Selectable background colour

Background colours

Black

Black/white scanning colour modes

Grayscale

Maximum scan size

216 x 3000 mm

Optical scanning resolution

600 x 600 DPI

Colour scanning

Yes

Duplex scanning

Yes

Input colour depth

30 bit

Output colour depth

24 bit

Film scanning

Greyscale levels

256

ADF scan speed (b/w- A4)

40 ppm

ADF scan speed (colour- A4)

40 ppm

Flatbed scan speed (b/w- A4)

5 sec/page

Duplex ADF scan speed (b/w- A4)

80 ipm

Duplex ADF scan speed (colour- A4)

80 ipm

ADF scan speed (greyscale- A4)

40 ppm

Flatbed scan speed (colour- A6)

3 sec/page

Sensor type

CMOS dual CIS

Light source

RGB LED

Scan file formats

BMP- JPG- OCR- PDF- PNG- RTF- TIFF- XLS

Daily duty cycle (max)

5000 pages

Scan to

Cloud- E-mail- E-mail Server- Fax- File- Image- OCR- SMB- WIA

Design

Built-in display

Yes

Touchscreen

Scanner type

ADF scanner

Display diagonal

3.81 cm (1.5")

Display

LCD

Product colour

Black- White

Performance

Text-to-speech technology

Built-in translator

Barcode reader

Yes

Button functions

Cancel- down- Off- On- Scan- Up

Sensor type

CMOS dual CIS

Light source

RGB LED

Scan file formats

BMP- JPG- OCR- PDF- PNG- RTF- TIFF- XLS

Daily duty cycle (max)

5000 pages

Scan to

Cloud- E-mail- E-mail Server- Fax- File- Image- OCR- SMB- WIA

Scan drivers

ISIS-SANE-TWAIN-WIA

Scanning noise level

50 dB

Processor frequency

1500 MHz

Built-in processor

Yes

Ultrasonic double sheet detection

Yes

Scanner error detection

Yes

Input capacity

Standard input capacity

80 sheets

Auto document feeder (ADF) input capacity

80 sheets

Paper handling

Maximum scan width

21.6 cm

Maximum scan length

3 m

Maximum ISO A-series paper size

Scanning media types supported

Business Card- Card stock- Envelopes- Plain paper- Plastic Card- Post Card(JPN)- Recycled paper- Thick paper- Thin paper

Maximum scan area (ADF)

216 x 356 mm

Minimum scan area (ADF)

52 x 52 mm

Auto Document Feeder (ADF) media weight

27 - 433 g/mÂ²

Multi feed detection

Yes

Letter

Yes

Legal

Yes

ISO B-series sizes (B0...B9)

B5-B6-B7-B8

ISO A-series sizes (A0...A9)

A3-A4-A5-A6-A7-A8

Long-paper mode

Yes

Ports & interfaces

USB connector type

USB Type-B

TV-out

Standard interfaces

USB 3.2 Gen 1 (3.1 Gen 1)

USB port

Yes

USB version

3.2 Gen 2 (3.1 Gen 2)

Software

Windows operating systems supported

Windows 10-Windows 10 Education-Windows 10 Education x64-Windows 10 Enterprise-Windows 10 Enterprise x64-Windows 10 Home-Windows 10 Home x64-Windows 10 Pro-Windows 10 Pro x64-Windows 7-Windows 7 Enterprise-Windows 7 Enterprise x64-Windows 7 Home Basic-Windows 7 Home Basic x64-Windows 7 Home Premium-Windows 7 Home Premium x64-Windows 7 Professional-Windows 7 Professional x64-Windows 7 Starter-Windows 7 Starter x64-Windows 7 Ultimate-Windows 7 Ultimate x64-Windows 7 x64-Windows 8-Windows 8 Enterprise-Windows 8 Enterprise x64-Windows 8 Pro-Windows 8 Pro x64-Windows 8 x64-Windows 8.1-Windows 8.1 Enterprise-Windows 8.1 Enterprise x64-Windows 8.1 Pro-Windows 8.1 Pro x64-Windows 8.1 x64

Bundled software

WINDOWS Bundled software: TWAIN- ISIS- WIA Drivers; Alaris Capture Pro Limited- Alaris Smart Touch- LINUX drivers- KOFAX certified.

Scan drivers

ISIS-SANE-TWAIN-WIA

Drivers included

Yes

Sound emission

Scanning noise level

50 dB

Power

Auto power off

Yes

Power consumption (typical)

36 W

Power consumption (standby)

3 W

Power consumption (off)

0.5 W

Input voltage

100-240 V

Power supply type

Power supply

36 W

Power consumption (PowerSave)

3 W

AC input frequency

50 - 60 Hz

Technical details

Maximum scan width

21.6 cm

Black/white scanning colour modes

Grayscale

Button functions

Cancel- down- Off- On- Scan- Up

Scanner type

ADF scanner

Product colour

Black- White

Scan technology

Dual CIS

Programming function

Yes

PC connection

USB 3.2 Gen 1 (3.1 Gen 1)

Linear (1D) barcodes supported

Codabar-Code 128-Code 3 of 9-Code 39-Code 93-EAN-13-EAN-8-Interleaved 2 of 5-PDF417-U.P.C.

Relative humidity

15 - 80%

Maximum paper size

216 x 3000 mm

Power

36 W

Sustainability certificates

RoHS- ENERGY STAR

Processor

Processor frequency

1500 MHz

Built-in processor

Yes

Display

Touchscreen

Display diagonal

3.81 cm (1.5")

Display

LCD

Media formats

Letter

Yes

Legal

Yes

ISO B-series sizes (B0...B9)

B5-B6-B7-B8

ISO A-series sizes (A0...A9)

A3-A4-A5-A6-A7-A8

System requirements

Windows operating systems supported

Minimum RAM

4000 MB

Minimum processor

Intel i3

Operational conditions

Operating temperature (T-T)

10 - 35 Â°C

Operating relative humidity (H-H)

15 - 80%

Certificates

Green (Eco) compliant

Yes

Certification

EPEAT Registered ENERGY STAR Qualified AS/NZS CISPR 22:2009 +A1:2010; (Class B RCM mark)- CAN / CSA â C22.2 No 60950-1-07 +A1:2011 (TUV C mark)- Canada CSA-CISPR 22-10 / ICES-003 Issue 5 (Class B)- China GB4943.1:2011; GB9254:2008 Class B (CCC S&E mark)- EN55022:2010 ITE Emissions (Class B)- EN55024:2010 ITE Immunity (CE mark)- EN60950-1:2006 +A1-+A11-+A12 (TUV GS mark)- IEC60950-1:2005 +A1- Taiwan CNS 13438:2006 (Class B); CNS 14336-1 (BSMI mark)- UL 60950-1:2007 R12.11 (TUV US mark)- CFR 47 Part 15 (FCC Class B)- Argentina S mark

Weight & dimensions

Width

312 mm

Depth

204 mm

Height

183 mm

Weight

3.3 kg

Packaging content

Quick start guide

Yes
