ASUS WS X299 SAGE server/workstation motherboard LGA 2066 SSI CEB Intel X299
In Stock
|
Technical details
Motherboard chipset
Intel® X299
Parallel processing technology support
4-Way CrossFireX-4-Way SLI
Number of processors supported
1
Number of DIMM slots
8
Motherboard form factor
SSI CEB
Audio
Audio output channels
7.1 channels
Performance
Motherboard chipset
Intel® X299
RAID levels
0-1-5-10
Audio output channels
7.1 channels
Motherboard form factor
SSI CEB
Processor
Processor manufacturer
Intel
Compatible processor series
Intel® Core™ X-series
Processor socket
LGA 2066 (Socket R4)
Memory
Supported memory types
DDR4-SDRAM
Non-ECC
Yes
Supported memory clock speeds
2133-2400-2666-3600-4000-4133-4200 MHz
Maximum internal memory
128 GB
Storage controllers
Supported storage drive interfaces
SATA III
RAID levels
0-1-5-10
RAID support
Yes
Graphics
Parallel processing technology support
4-Way CrossFireX-4-Way SLI
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Supported storage drive interfaces
SATA III
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Number of SATA III connectors
8
Number of COM connectors
1
Number of chassis fan connectors
2
EPS power connector (8-pin)
Yes
CPU fan connector
Yes
ATX Power connector (24-pin)
Yes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB 2.0 ports quantity
4
Ethernet LAN (RJ-45) ports
2
Network
Ethernet LAN
Yes
Wi-Fi
No
LAN controller
Intel® I210-AT- Intel I219LM
Ethernet interface type
Gigabit Ethernet
Features
Motherboard chipset
Intel® X299
Audio output channels
7.1 channels
Motherboard form factor
SSI CEB
Expansion slots
PCI Express x16 slots
7
BIOS
Clear CMOS button
Yes
Operational conditions
Storage temperature (T-T)
-40 - 70 °C
Operating temperature (T-T)
10 - 35 °C
Storage relative humidity (H-H)
20 - 90%
Weight & dimensions
Width
305 mm
Depth
267 mm
Packaging content
Cables included
SATA
User guide
Yes
Other features
Number of processors supported
1
Number of DIMM slots
8
ASUS WS X299 SAGE server/workstation motherboard LGA 2066 SSI CEB Intel X299
| Weight | 1.000000 lbs |
