Technical details
Product type
Group video conferencing system
Tilt angle range
-15 - 15°
Pan range
-25 - 25°
Product colour
Graphite
PTZ control
Yes
Video
HD type
4K Ultra HD
Digital zoom
4x
Supported video modes
720p-900p-1440p-2160p
Maximum frame rate
30 fps
Audio
Microphone pick-up range
4.5 m
Output level
90/99 dB
Output voltage Total Harmonic Distortion (THD)
2%
Built-in speaker(s)
Yes
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Microphone in
Yes
Interface module
Interface module HDMI ports quantity
3
Interface module Ethernet LAN (RJ-45) ports
1
Interface module HDMI input ports quantity
1
Interface module HDMI output ports quantity
2
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10-100-1000 Mbit/s
Wi-Fi
Yes
Wi-Fi standards
802.11a-802.11b-802.11g-Wi-Fi 4 (802.11n)-Wi-Fi 5 (802.11ac)
Security algorithms
128-bit AES
Camera
Field of view (FOV) angle
120°
Horizontal field of view
113°
Remote control interface
Bluetooth
Microphone
Microphone sensitivity
-36 dB
Microphone frequency
90 - 16000 Hz
Number of microphones
6
Sound pressure level (max)
90 dB
Security
Security algorithms
128-bit AES
Features
Telepresence
No
Logistics data
Master (outer) case width
20 cm
Master (outer) case gross weight
6.29 kg
Master (outer) case length
80.4 cm
Master (outer) case height
21.2 cm
Operational conditions
Storage temperature (T-T)
-40 - 70 °C
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 95%
Heat dissipation
64 BTU/h
Power
DC input voltage
19 V
AC input voltage
100 - 240 V
Current
4.754 A
Power source type
AC
Power plug type
Type G
Weight & dimensions
Width
719 mm
Depth
101 mm
Height
91.4 mm
Weight
4.03 kg
Package width
191 mm
Package depth
789 mm
Package height
199 mm
Package weight
5.8 kg
Packaging content
Remote control included
Yes
Cables included
AC- DC- HDMI- USB Type-A to USB Type-C
Power cable length
2.5 m
HDMI cable length
2 m
Rally Bar Mini - Videokonferenzkomponente
Length | 10.10 in |
Width | 71.90 in |
Height | 9.14 in |
Weight | 4.030000 lbs |
