Intel NUC NUC10i7FNHN UCFF Black i7-10710U 1.1 GHz
In Stock
|
Motherboard
Motherboard form factor
UCFF
Processor
Thermal Design Power (TDP)
25 W
Built-in processor
Yes
Processor model
i7-10710U
Processor boost frequency
4.7 GHz
Processor threads
12
Processor frequency
1.1 GHz
Processor lithography
14 nm
Processor cores
6
Processor family
10th gen Intel® Core™ i7
Processor manufacturer
Intel
CPU configuration (max)
1
Memory bandwidth supported by processor (max)
42.6 GB/s
Processor cache
12 MB
Memory
Memory voltage
1.2 V
Memory slots type
SO-DIMM
Number of memory slots
2
Memory channels
Dual-channel
Memory bandwidth (max)
42.6 GB/s
ECC
No
Supported memory types
DDR4-SDRAM
Supported memory clock speeds
2666 MHz
Maximum internal memory
64 GB
Non-ECC
Yes
Removable memory card slot
SDXC with UHS-II support
Number of DIMM slots
2
Video
On-board graphics adapter
No
Storage
Supported storage drive types
HDD & SSD
Storage drive sizes supported
M.2-2.5
Storage drive interface
M.2- Serial ATA III
Number of storage drives supported
2
RAID levels
0-1
Compatible memory cards
SD-SDHC-SDXC
Card reader integrated
Yes
SSD form factor
M.2
Graphics
Number of displays supported
3
On-board graphics adapter
No
On-board graphics adapter model
Intel® UHD Graphics
Audio
Intel® High Definition Audio (Intel® HD Audio)
No
Audio output channels
7.1 channels
Built-in speaker(s)
No
Network
Wi-Fi standards
Wi-Fi 6 (802.11ax)
Bluetooth version
5.2
Bluetooth
Yes
Ethernet LAN
Yes
Wi-Fi
Yes
LAN controller
Intel® I219-V
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
WLAN controller model
Intel Wi-Fi 6 AX201
Ports & interfaces
Combo headphone/mic port
Yes
Number of SATA III connectors
2
DC-in jack
Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
Internal USB 2.0 ports quantity
2
HDMI version
2.0b
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
USB version
2.0/3.2 Gen 2 (3.1 Gen 2)
USB ports quantity
7
Thunderbolt 3 ports quantity
1
M.2 card slot (storage)
2242/2280
Expansion slots
PCI Express slots version
3.0
Design
Motherboard form factor
UCFF
Product type
Mini PC barebone
ARK ID
214598
On/off switch
Yes
Cooling type
Active
Product colour
Black
Chassis type
UCFF
Status
Launched
Performance
Motherboard form factor
UCFF
Windows operating systems supported
Windows 10 x64
Number of displays supported
3
Trusted Platform Module (TPM)
No
Compatible operating systems
Windows 10- 64-bit*
Audio output channels
7.1 channels
Commodity Classification Automated Tracking System (CCATS)
G157815L2
Harmonized System (HS) code
8471500150
Export Control Classification Number (ECCN)
5A992C
Consumer infrared Rx sensor
Yes
Software
Compatible operating systems
Windows 10- 64-bit*
Processor special features
Intel TSX-NI
No
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Trusted Execution Technology
No
Intel Flex Memory Access
Yes
Intel 64
Yes
Idle States
Yes
Execute Disable Bit
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Clear Video Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Optane™ Memory Ready
Yes
Intel Rapid Storage Technology
Yes
Intel® High Definition Audio (Intel® HD Audio)
No
Embedded options available
No
Intel® Platform Trust Technology (Intel® PTT)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel® vPro™ Platform Eligibility
No
Colour
Product colour
Black
Power
DC input voltage
19 V
Power supply type
External AC adapter
Technical details
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Rapid Storage Technology
Yes
Intel® High Definition Audio (Intel® HD Audio)
No
Embedded options available
No
Trusted Platform Module (TPM)
No
RAID levels
0-1
Processor cores
6
Cooling type
Active
Chassis type
UCFF
ARK ID
214598
Internal I/O
Number of SATA connectors
2
Packaging data
Power cord included
Yes
Management features
On/off switch
Yes
Features
Number of displays supported
3
Weight & dimensions
Width
117 mm
Depth
112 mm
Height
51 mm
Packaging content
Power cord included
Yes
Other features
DC input voltage
19 V
Embedded options available
No
Number of SATA connectors
2
HDD size
2.5"
Chassis type
UCFF
Additional headers
CEC- 2x USB2.0- FRONT_PANEL- RGB
Launch date
Q2'21
Intel NUC NUC10i7FNHN UCFF Black i7-10710U 1.1 GHz
| Weight | 1.410000 lbs |
