Power
Output voltage regulation
0.01
Output frequency regulation
50/60 Hz
Output power
900 W
Input operation voltage (min)
220 V
Input operation voltage (max)
240 V
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Efficiency
0.89
Power factor
0.9
Input current Total Harmonic Distortion (THD)
0.05
Crest factor
0.12569444444444
Output power capacity
1000 VA
Total Harmonic Distortion (THD) (linear load)
0.01
Total Harmonic Distortion (THD) (non-linear load)
0.05
Charging current
1.5 A
Efficiency (ECO mode)
0.97
Performance
UPS topology
Double-conversion (Online)
Waveform
Pure sine
Number of output phases
1
Number of input phases
1
Transfer time (Inverter Mode to ECO Mode)
4 ms
Features
UPS topology
Double-conversion (Online)
Waveform
Pure sine
Output voltage regulation
0.01
Output frequency regulation
50/60 Hz
Number of output phases
1
Number of input phases
1
Output power
900 W
Input operation voltage (min)
220 V
Input operation voltage (max)
240 V
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Efficiency
0.89
Power factor
0.9
Input current Total Harmonic Distortion (THD)
0.05
Crest factor
0.12569444444444
Output power capacity
1000 VA
Total Harmonic Distortion (THD) (linear load)
0.01
Total Harmonic Distortion (THD) (non-linear load)
0.05
Transfer time (Inverter Mode to ECO Mode)
4 ms
Efficiency (ECO mode)
0.97
Input frequency
50/60 Hz
Charging current
1.5 A
Ports & interfaces
USB port
Yes
AC outlets quantity
4 AC outlet(s)
AC outlet types
C13 coupler
Battery
Typical backup time at full load
3.5 min
Charging current
1.5 A
Design
Form factor
Compact
Product colour
Black
Safety
EN62040-1
Display
LCD
Operational conditions
Operating temperature (T-T)
0 - 40 ‚°C
Storage temperature (T-T)
-10 - 50 ‚°C
Operating relative humidity (H-H)
0 - 90%
Operating altitude
0 - 1000 m
Technical details
Output voltage
24 V
Weight & dimensions
Weight
9.2 kg
Width
144 mm
Height
356 mm
Depth
228 mm
Other features
Output voltage
24 V
Certa UPS MTS-55L-HORZ
Length | 22.80 in |
Width | 14.40 in |
Height | 35.60 in |
Weight | 9.200000 lbs |
