StarTech Gigabit Ethernet to SC Fiber Media Converter - 1000Base-LX - Single-mode - 10 km
In Stock
|
Network
Fiber optic connector
SC
Jumbo frames support
Yes
Store-and-forward
Yes
Jumbo frames
9000
Converter input interface
10Base-T-100Base-TX-1000Base-T
Networking standards
IEEE 802.1Q-IEEE 802.3-IEEE 802.3ab-IEEE 802.3u-IEEE 802.3x
Ethernet LAN data rates
10-100-1000 Mbit/s
Ethernet interface type
Fast Ethernet- Gigabit Ethernet
Duplex system
Full
Converter output interface
100Base-LX
Auto MDI/MDI-X
Yes
Maximum data transfer rate
1000 Mbit/s
Technical details
Wavelength
1310 nm
Maximum transfer distance
10000 m
Fiber mode structure
Single-mode
Internal
No
Sustainability certificates
RoHS
Performance
Jumbo frames support
Yes
Store-and-forward
Yes
Wavelength-division multiplexing (WDM)
No
Wavelength
1310 nm
Maximum transfer distance
10000 m
Fiber mode structure
Single-mode
Mean time between failures (MTBF)
50000 h
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Fiber ports quantity
1
Fiber optic connector
SC
Indication
LED indicators
Activity- Link- Power
Design
LED indicators
Activity- Link- Power
Product colour
Black
Certification
CE- FCC
Internal
No
Endurance
Mean time between failures (MTBF)
50000 h
Power
Power plug type
Type N
Input voltage
100 - 240 V
Input current
0.5 A
Output voltage
5 V
Output current
2.6 A
External power adapter
Yes
Colour
Product colour
Black
Weight & dimensions
Width
105 mm
Depth
70 mm
Weight
196 g
Height
26 mm
Package depth
285 mm
Package width
138 mm
Package height
66 mm
Package weight
560 g
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Packaging data
Package depth
285 mm
Package width
138 mm
Package height
66 mm
Package weight
560 g
Packaging content
Quick installation guide
Yes
AC adapter included
Yes
Certificates
Certification
CE- FCC
StarTech Gigabit Ethernet to SC Fiber Media Converter - 1000Base-LX - Single-mode - 10 km
| Weight | 1.000000 lbs |
