D-Link DXS-1210-28S network switch Managed 10G Ethernet (100/1000/10000) Black 1U
In Stock
|
Network
IGMP snooping
Yes
GARP VLAN Registration Protocol (GVRP)
Yes
Cable types supported
Cat6-Cat6a-Cat7
Networking standards
IEEE 802.3ab-IEEE 802.3ae-IEEE 802.3an-IEEE 802.3az-IEEE 802.3u-IEEE 802.3z
VLAN support
Yes
Spanning tree protocol
Yes
Port mirroring
Yes
Number of VLANs
4094
Link aggregation
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
10G support
Yes
Virtual LAN features
VLAN support
Yes
Number of VLANs
4094
Data transmission
Number of VLANs
4094
Jumbo frames
9000
Throughput
416.64 Mpps
MAC address table
32000 entries
Switching capacity
560 Gbit/s
Store-and-forward
Yes
Jumbo frames support
Yes
Technical details
Form factor
1U
Product colour
Black
Rack mounting
Yes
Management features
Switch type
Managed
Web-based management
Yes
Quality of Service (QoS) support
Yes
Ports & interfaces
SFP+ module slots quantity
24
Basic switching RJ-45 Ethernet ports quantity
4
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Console port
RJ-45
Security
Access Control List (ACL) rules
256
IGMP snooping
Yes
Access Control List (ACL)
Yes
Protocols
Management protocols
SNMP v1/v2c/v3
GARP VLAN Registration Protocol (GVRP)
Yes
Certificates
Certification
CE Class AFCC Class AVCCI Class AICBSMI
Design
Form factor
1U
Product colour
Black
LED indicators
Activity- Link- Speed
Certification
CE Class AFCC Class AVCCI Class AICBSMI
Rack mounting
Yes
Number of fans
2 fan(s)
Indication
LED indicators
Activity- Link- Speed
Mobile network
GARP VLAN Registration Protocol (GVRP)
Yes
Power
Power consumption (max)
85.7 W
AC input voltage
100 - 240 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Storage temperature (T-T)
-20 - 70 °C
Storage relative humidity (H-H)
0 - 95%
Operating temperature (T-T)
-5 - 50 °C
Operating relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
441 mm
Depth
209.5 mm
Height
44 mm
Weight
3.27 kg
Packaging data
Manual
Yes
Packaging content
Manual
Yes
D-Link DXS-1210-28S network switch Managed 10G Ethernet (100/1000/10000) Black 1U
| Length | 20.95 in |
| Width | 44.10 in |
| Height | 4.40 in |
| Weight | 3.270000 lbs |
